Refrigerated freezer used vacuum insulation panel VIP Panel
Product Details:
| Place of Origin: | Chuzhou |
|
Detail Information |
|||
| High Light: | refrigerator VIP panel,vacuum insulation panel,freezer panel |
||
|---|---|---|---|
Product Description
Refrigerated and freezer used vacuum insulation panel VIP panel
Main Customer: GE, Sumsang, LG, Haier, Haisense, Siemens, Meiling, Midea, etc.
Yinxing starts Vacuum Insulation Panel (VIP) R&D since 2005, and in 2008, we have began the mass production for GE.
Until now, Yinxing has become one of the largest VIP manufacturer and supplier in China.
VIP provides a value of thermal conductivity which is 7-10 times lower than traditional insulation material.
Specification:
Item | Data |
Temperature Stability | -50～70 ℃ |
Density | 240-320 kg/m3 |
Thermal Conductivity | ≤3.5, ≤2.5，≤2.0，≤1.7 mw/m·K |
Thickness | 2～50 mm |
Maximum Size | 1880*850mm |
Standard Size | 1440*500mm; 600*500mm |
Service Life | According to the customer's request |
Core Material | glass fiber; fumed silica (SiO2); choped glass fiber |
Shape | Triangle, trapezium, special shape, cornet cut, hole cut and recessed surface |
Applications:
1.Refrigerated containers
2.Refrigerator, freezer, vending machine
3.Medical Refrigerators and freezers
4.Marine and recreational refrigeration vehicles
5.Civil refrigeration equipment
6.Construction Insulation
VIP Feature
1. 7- 10 times better insulation effect then conventional insulations
2. Thin, and light;
3. Extremely low thermal conductivity 0.002w/m. K
4. Resistance to heat transfer among the gas molecules
5. Non-ODS material
6. Not harmful to the environment
