Constant Temperature Blood Medical Refrigerator Freezer BT-5 for Hospital
Product Details:
| Place of Origin: | China |
| Brand Name: | Bestran |
| Certification: | ISO13485,CE |
| Model Number: | BT-5 |
| Product name: | Medical Refrigerator Freezer |
|---|---|
| Power Source: | Electricity |
| Voltage(V/Hz): | 220/50 |
| Type: | BT-5 |
| power(W): | 166 |
| temperature(°C): | 20~24 |
| alarm system: | 5-ways alarm system |
| Applications: | blood plasma,vaccine,biological,chemical |
|
Detail Information |
|||
| High Light: | blood bank refrigerator,vaccine refrigerator,medical refrigerators |
||
|---|---|---|---|
Product Description
Constant Temperature Blood Medical Refrigerator Freezer BT-5 for Hospital
Quick Detail:
The single deep freezer has 5 drawers
The vertical freezer has the constant temperature from 20C~24C
The chiller and freezer has disinfection with UV
The voltage of the freezer unit is from 187V to 242V
Applications:
1.Keeps a temperature range of 20°C-24°C during blood platelet infusion, while swinging to avoid the platelet
cohesion.
2.Suitable for hospitals, blood stations, labs and other places
Description:
Temperature Control
High accuracy sensor
Microprocessor-based temperature controller, inner temperature ranges between 22±2°C
Safety
Alarms: higher and lower temperature alarms, sensor breakdown alarm, door open alarm, power off alarm,
time delay alarm.
Two alarm styles: buzzing, flashing
Power cable protection against electric leakage
Refrigerating System
Branded compressor, environmental protection non- CFC refrigerant with high efficiency
High density insulation layer
Branded air-cooling with excellent performance
Humanized Design
Disinfection with UV
Temperature printer can be set by demands, monitoring temperature change at any time
Wide voltage range design from 187V to 242V.
Specification:
|
Type |
Size (mm) |
voltage(V/Hz) |
power(W) |
temperature(°C) |
Climate type |
effective volume |
net weight(Kg) |
||
|
Width/W |
Depth/D |
heith/H |
|||||||
|
BT-5 |
540 |
590 |
960 |
220/50 |
166 |
20~24 |
SN |
5 layers |
98 |
photos of the commercial deep freezer:
photos of the upright showcase freezer
photos of the industrial deep freezers:
photos of the 6 door freezer:
FAQ:
Q: 1. what is the lead time?
A: Normally 15-20 days
Q: 2. Can you put our logo on product?
A: Yes, please provide the finished design of your logo; we will make it into stickers.
Q: 3. how is your warranty?
A: 2 years on unit, 3 years on compressor
Q: 4. Do you accept OEM service
A: Yes, OEM service available, please provide your drawing and detailed specification.
Q: 5. What kind of voltage and frequecncy is available?
A: 220V/50Hz,110V/60Hz are available, or others as per customers’ requirement
Q: 6. Could you do our country’s plug?
A: Yes
Q: 7. Could you make the printing artworks(such as user manual/packing/rating label) in our language?
A: Yes
Q: 8. Could we order samples
A: Yes
